What is a CXP fiber optic transceiver module?

What is a CXP fiber optic transceiver module?

CXP fiber optic module is another high-speed optical module in the 100G optical module market. However, due to the wide application of QSFP28 fiber optic transceiver module, the fame of CXP fiber optic transceiver module is not so prominent in comparison.


What is a CXP fiber optic transceiver module?


CXP fiber optic transceiver module is 45mm long and 27mm wide, slightly larger than XFP optical module. Built in 12 transmission channels, each operating at a speed of 10Gb/s, with a maximum speed of 120G, mainly used to meet the high-density needs of data centers, typically used in conjunction with parallel multimode fiber strips, with transmission distances up to 100 meters.


CXP fiber optic transceiver module supports hot plug. C "represents 12 in hexadecimal, the Roman numeral" X "represents a transmission rate of 10Gbps per channel, and" P "refers to a pluggable device that supports hot swapping. CXP fiber optic transceiver module is mainly aimed at the high-speed computer market and is a supplement to CFP fiber optic transceiver module in the Ethernet data center. In addition, CXP fiber optic transceiver module is a copper connector system designated by the Wireless Broadband Trade Association, which can support 12 10G link transmissions for 100GbE, 3 for 40GbE channels, or 12 for 10G Ethernet Fibre Channel or wireless broadband signals QDR link transmission.


What is a CXP fiber optic transceiver module?


The main technologies of CXP fiber optic transceiver module


CXP fiber optic transceiver module mainly applies 850nm VCSEL array technology, PIN array, integrated laser driver chip and other technologies. VCSEL has the characteristics of low threshold current, low power consumption, high modulation rate, easy coupling of circular emission spot, and easy fabrication into an array; PIN has the characteristics of high sensitivity, fast response rate, low reverse bias, and low power consumption;

CXP fiber optic transceiver module Features


l12 Tongda Full Duplex Transceiver Module

lHot swappable cxp socket

lMaximum link length of 300 meters OM3 or 400 meters OM4 multimode fiber (MMF)

lMulti rate capability: 1.06 gb/s to 10.5gb/s/channel

lUnretimed CPPI electrical interface

l3.3 V power supply

lLow power consumption: "4.5 W

lReliable VCSEL array technology

lBuilt-in digital diagnostic function

lWorking temperature: 0 ° C to 70 ° C

lSingle MPO connector socket

lMeets RoHS6 (lead-free)
